14
Menu System
Menu System
Using the Features menu you can:
a) Select if you want to listen to the sound from the projection TV directly or through an external amplifier.
b) Select a time period after which the projection TV switches itself into standby mode.
c) Lock the buttons on the projection TV set. In this way, the projection TV only works by using the remote control buttons.
d) Select the source to be output from the Scart connector :2/q2 (SMARTLINK). In this way you can record from this scart
connector while watching another source. If your VCR supports Smartlink, this procedure is not necessary.
Using the Features Menu
1 Press the MENU button on the remote control to display the menu
on the screen.
2 Push the joystick to $ to select the symbol, then push to z to
enter to the Features menu.
3 Push the joystick to $ or 4 to select the desired menu item, then
push to z (see the table below for the effect of each menu item).
4 Push to $ or 4 to select the desired setting and press the OK button
to store.
5 Press the MENU button to exit and return to the normal TV screen.
Features Effect / Operation
Speaker $ Main (sound from projection TV set)
4 Centre In (sound from external amplifier)
Sleep Timer
4 Off
10 min.
20 min.
...
$ 90 min.
• One minute before the projection TV switches
into standby mode, the time remaining is
displayed on the screen automatically.
• When watching the TV, press the button on
the remote control to display the time remaining.
• To return to normal operation from standby
mode, press the TV button on the remote
control.
Parental lock $ Off (Normal mode)
4 On (The projection TV can only be switched on
using the remote control, the buttons on the
TV do not work)
AV2 Output $ TV (audio/video signal from the aerial)
AV1
(audio/video signal from the Scart
connector :1/ ).
AV2 (audio/video signal from the Scart
connector
:
2/q2 (SMARTLINK).
AV3 (audio/video signal from the Scart
connector
:
3/q3).
4 AV4 (audio/video signal from the connector 4
placed in the front of the Projection TV).
If you have connected a decoder, please remember
to change back the AV2 Output to "TV" for correct
unscrambling.
Picture Adjustment
Select: Enter Menu:
Picture Mode
Contrast
Brightness
Colour
Sharpness
Reset
AI
Noise Detection
Digital Mode
Personal
On
On
DRC 50
Features
Sleep Timer
Parental Lock
AV2 Output
Off
Off
TV
Select: Enter:
Speaker
Main
Speaker
Main
Centre In
10 min
Sleep Timer
Parental Lock
Off
On
AV2 Output
TV
AV1
AV2
AV3
AV4
S
RM
892
PROGR
MENU
1
4
7
2
5
8
0
3
6
9
VIDEO TV
