Chapter 5. Device Management
115
Use this icon to enable broadcasting. Broadcasting allows you to
access and make changes on a single port and the same changes
will be made across all Broadcast Ports. Before using the
broadcast function, set the Broadcast Timeout and Broadcast Ports
(See the SN device manual for more information).
For broadcasting to work, you must first access a port set as a
Broadcast Port and then click the Broadcast icon on the control
panel.
Click to send a Break command.
Use this to reset the terminal to its default settings.
Click to bring up the Message Board (See the SN device manual
for more information).
Click to open a window and create a list of custom text macros
(See the SN device manual for more information).
Use this to change the font, color and other SNViewer settings
(See the SN device manual for more information).
Use this button to adjust the width of the SNViewer window.
Click to exit the viewer.
Icon Function
