Chapter 7. System
227
Key the amount of time (in minutes) a locked out user must wait before
being allowed to log in again in the Timeout field. The value specified here
must be at least 1. The default is 30.
Enabling Require manual unlock, means that users will not be able to log
in after their account has been locked until they contact an administrator to
have the administrator manually unlock the account. See Unblock User,
page 152, for details. The default is disabled (no check in the checkbox).
User role restriction policy
This setting category allows an administrator to create user accounts with
either no role restrictions or with one of three pre-set role restriction policies.
Options are as follows:
No role restrictions
Restrict system management roles (1–2)
Restrict system and user management roles (1–5)
Restrict all roles (1–9)
Note: For full details of roles 1–9, please see the table under System User
Types, page 153.
Power control
This setting category allows an administrator to set power control over devices
and servers for users.
Enabling Force to confirm all power operation means the users are forced to
make power operation confirmation on all of the connected devices regardless
of the setting on the outlet.
Enabling Enable power control for servers means if the third-party servers
supports power control, they are allowed to perform power control. Otherwise,
the related power control functions will be removed from the menu.
