4. Playback Data

The Playback Data function allows viewing data from last test

recorded by the scan tool.

NOTE: The amount of files that can be saved depends on the

space available in the SD card.

4.1 Reviewing Data

1) Use the LEFT/RIGHT scroll button to select Playback from

Main Screen (Figure 3.1), and press the OK button. Wait for

the Scan screen to appear. (Figure 4.1)

2) To review the data saved in the scan function, select SCAN in

the Replay menu. To review the data in the saved EPB

function, select EPB in the reply menu. Then press OK to

continue.

3) Use the UP/DOWN scroll button to select the desired item from

Scan screen, and press the OK button.

Replay

1.EPB

2.Scan
