19
Figure 4.1
If no data from previously tested vehicle is recorded, a message
“No data available!” shows on the screen.
4) Review selected data on screen. (Figure 4.2 )
Figure 4.2
4.2 Deleting Data
By selecting Delete on the Scan screen, you are allowed to erase the
selected data on the scan tool. Review the recordings thoroughly
before erasing. You could also erase all recordings by select Delete
All.
NOTE: Don’t use Delete All unless you are definitely sure what
you are going to proceed.
Scan
1. UITrouble
/scan/MAKE/USA/FORD/
2. UIDatastream: complete list
/scan/make/EOBD/
3. UIFreeze
/scan/make/USA/
Delete Delete All
Vehicle Specification
Vehicle: Mustang
Engine Type: Other
Capacity: 3.8L
Transmission: Manual
Fuel Type: Gasoline
Emission Level: Federal Emission
VIN:1FAFP40462F100819
PrefSuf:2R3APB VersionID:4612
Print
www.autel-russia.ru
