Autel MOT PRO — troubleshooting LINKING ERROR in Vehicle Scan Tool [34/157]

If the “LINKING ERROR” message does not go away, then

there might be problems for the scan tool to communicate

with the vehicle. Contact your local distributor or the

manufacturer’s customer service department for assistance.

7） View a summary of system status (MIL status, DTC counts,

Monitor status) on screen. (Figure 6.1 ) Press OK button for

Diagnostic Menu (Figure 6.3) to come up.

Figure 6.1

If more than one module is detected, you will be prompted to

select a module before testing. (Figure 6.2 )

Figure 6.2

Use the UP/DOWN scroll button to select a module and press

the OK button.

6.1. Read Codes

 Reading Codes can be done with the key on engine off (KOEO)

Control Module

1. Engine

2. Module $A4

System Status

MIL Status

OFF

Codes Found

Monitors N/A

Monitors OK

Monitors INC

Save OK
