Figure 9.9

When the resetting is finished, the tool will display a

confirmation message.

Figure 9.10

5) The BSI option enables you to finish oil reset service

automatically and manually. The procedures work as below.

In the Oil Reset menu, select Resetting to zero of the

service mileage function and press OK button.

Figure 9.11

Service Zero Reset

Check the resetting of

the maintenance to zero.

Cancel

Service Zero Reset

Operation Completed.

Press any key to continue

Oil Reset

1.Resetting to zero of the service

mileage

2.Maintenance

www.autel-russia.ru
