Руководство пользователя Страница: 77

Autel MOT PRO [77/157] Www autel russia ru

Figure 11.4

2) In the EPB screen, use the UP/DOWN button to select Brake

cable replacement. The screen shows as below.

Figure 11.5

In the Brake cable replacement screen, the tool can perform

three functions.

A. Put in fitting or removal position

This function enables you to fit in or remove the brake cable

safely and easily. It will take a few seconds to execute this

command.

EPB

1.Brake cable replacement

2.Electric parking brake

replacement.

Brake cable replacement

1.Put in fitting/removal position

2.Cable tensioning

3.Electric parking brake

calibration.

Put in fitting/removal position

Activation in progress!
