Autel MOT PRO [26/157] Www autel russia ru

To pop up the keyboard, press the Function button corresponding to

Show. Use UP/DOWN scroll button and LEFT/RIGHT scroll

button to select digit and character, and then press OK button to

confirm. Use Backspace button to delete the previous digit or

character. When finished, press the Function button corresponding

to Finish to proceed. The scan tool will identify the VIN code and

turn to diagnostic procedure.

Figure 5.14

5.2 Diagnostic test

After you have entered the correct vehicle information, the

diagnostic testing selection will display as below:

Figure 5.15

1) Auto Scan

Select An Option

1. Auto Scan

2. Control Unit

3. Vehicle Information

www.autel-russia.ru
