27
system, the scan tool will display an option list for you to view
different kind of DTCs or freeze frames.
Figure 5.17
In Auto Scan screen (Figure 5.16), pressing OK button will turn to
diagnostic operation. For more details, refer to 5.3 Diagnostic
Operation.
To exit the Auto Scan option, press ESC button. The scan tool will
display a message “Are you sure to quit?” to ask for your
confirmation. Select Yes to quit and No to cancel command.
2) Control Unit
Control Unit function will list down all the systems that might be
available on the vehicle for you to select to test. Select a system to
display the function menu and start testing.
Figure 5.18
System Menu
1. ABS/TCS
2. PCM
3. RCM
4. TCM
Select Option
1.CMDTCs(Continuous memory
diagnostic trouble codes)
2.Freeze Frame-Mode 2
3.pending
www.autel-russia.ru
