Руководство пользователя Страница: 25

Autel MOT PRO [25/157] Www autel russia ru

Figure 5.11

In the Benz Cars menu, choose the item “2. Select by entering

VIN” and you can enter the VIN code directly.

Figure 5.12

Figure 5.13

When you choose to enter VIN directly, a pop-up soft keyboard is

used to input VIN code. (Figure 5.14)

Cars

1.Vehicle record and abbreviation

2.Select by entering VIN

3.All model series

4.A-Class

5.B-Class

6.C-Class/CLK

7.E-Class/CLS

Select by entering VIN

If the chassis number does not

Match the vehicle, enter VIN as a

17-digit code.

Example:WDBNG70J02A123456

Finish Show Esc

www.autel-russia.ru
