DNS-6040M/DNS-6040 User’s Manual

address and password, and access file.

When adding the NAS server into a Windows or UNIX

NIS domain, Windows PDC or NIS server accounts are not able

to modify their personal details through

Storage Manager

. If

these users need to change some personal details, such as the

passwords or e-mail, please contact the system administrator of

the Windows PDC or NIS server.
