DNS-6040M/DNS-6040 User’s Manual
114
Backup only changed data
When files at the client are large and change frequently, if
every time any changes made to these files are updated
automatically to the backup in the server, this may cause busy
network traffic. Due to consideration of performance
efficiency, after running the complete backup in the first
instance user may choose not to run automatic monitoring, but
prefer to manually upload the changed files to D-Link NAS
Filer.
Or, after the user finished complete backup at the first
instance, if due to certain reasons (e.g. network disconnect) the
monitoring does not begin until files are changed, then you must
first backup the changed files to the server before running the
monitoring.
To backup any changed files, after you have selected the
file folders on your machine and destination server, click
Upload button on the right, select Modified files since last
upload to backup any changes made since last update or
Modified files since a designated time to backup any changes
since a specific point in time.
