DNS-6040M/DNS-6040 User’s Manual
18
TIP
If the administrator set a single-byte language (code page), such as English
or Multilingual, for Windows clients, an error will occur when the client
attempts to save double-byte files or folder names (e.g. Traditional Chinese)
on the NAS server, and some files cannot be deleted once saved. In this
case, the system administrator must use the Server Configuration
Language
Setup to change the code page to double-byte encoding; only then can the
file be properly accessed and deleted.
Enter a recipient for notification
The DNS-6040 Series
can notify the system administrator
of important events per e-mail. Enter a SMTP server and the
primary e-mail address. When an important event occurs, the
system administrators will be informed via e-mail and can
respond immediately, thus ensuring system safety. You have the
option to send a test message after setup to make sure you have
