DNS-6040M/DNS-6040 User’s Manual
33
Adding a shared folder
To add a folder, click on Create. The New Shared Folder
Setup page will appear. Enter a name and description for the
folder. If the system includes more than one volume, select a
volume under Folder Location. If the folder is to be shared
between normal users (Windows, Apple, Novell) and NFS users,
select Normal folder. If the folder is to be used only by NFS
users, select Export the folder by NFS only. Click OK to finish
or Next
to add another folder.
TIP
When using this system, Win 95/98 clients can only display folder names
with a maximum of 13 characters and Win NT clients can only display
folder names with a maximum of 12 characters. Therefore, when sharing
folders with Win95/98/NT clients, please pay attention to the length of the
folder names, otherwise clients may not be able to access these folders
through network neighborhood.
