DNS-6040M/DNS-6040 User’s Manual
34
Deleting a shared folder
To delete a shared folder, select the desired folder (use Ctrl
for multiple and Shift for continuous selection) in the list on the
left pane, then click Remove. The default shared folders “public
n” cannot be deleted.
Shared folder paths
The option Path is only available for NFS and cannot be
edited manually. The system will automatically enter the path
“/volumen/Shared_Folder_Name” for each shared folder on the
NAS server . For example, if you create a shared folder called
test on the first volume of the NAS server, the system will
automatically assign the path /volume1/test. This default value
cannot be changed by the administrator.
Once the shared folder is created, the system administrator
must use the Windows/Apple/Novell Privileges or NFS
Privileges tabs to choose users and their access privileges. All
files stored in the shared folder will have the same privileges.
