DNS-6040M/DNS-6040 User’s Manual
50
decimal point, underline and minus sign. The first character
however cannot be minus sign. The name is not case sensitive.
Please note:
When naming a group other than English, please input the
same language as the
Storage Manager
interface to ensure
correct coding. Thus, when interface language is Simplified
Chinese, group names can only be both Simplified Chinese and
English. Similarly, if the interface language is German, then
group names can only be German and English. The same
principle will be applied to other languages.
Default user groups
The system includes three default groups, admins (the
group of administrators with root as the default member), users
(normal users with their own home folders, with root as the
default member), and guests (normal users without their own
home folders, with guest as the default members).
admins － this is the system administrator group. Only
members of this group can change system settings.
Root
is a member of this group by default.
users
－
this is the user group to which all users belong.
Each member of this group can access his own
folder named after his account and other folders to
which he has access privileges. Root
is a member
of this group by default.
guests
－
unlike the members of the users group, guests will
not have their own home folders. They will
however have access to the public folders on the
NAS server. The account guest is a member of this
group by default.
