DNS-6040M/DNS-6040 User’s Manual
58
applied. Make sure the new quotas are correct. Click the Apply
button to update the values in the Current [In-Use/Quota](MB)
column. To cancel setup for a specific account, please select
an individual setup column and then click the <<Cancel button.
To cancel all the modification, click the Cancel button.
Please note if the
DNS-6040 Series
server is added to the
Windows NT/2000 domain and (1) system administrator has
previously added certain Windows PDC user account to Local
account in the Account Setup page or (2) there is an account in
both NAS server and Windows PDC with the same name, then
this account will not be displayed in columns NT Domain Users
or NIS Domain Users in the Current [In-Use/Quota](MB) List
at the left side of this page and will only be listed in Local Users
to prevent system administrator from being confused because of
repeated quota setup for the same user account.
