DNS-6040M/DNS-6040 User’s Manual
72
After a volume is created, system will return to main page
of the Volume Setting. At this time, the newly created volume
should be in normal working condition. The default “public n”
shared folder will also be created. System administrator can
also add other shared folders in this volume and make available
for clients to use.
TIP
Size to use is measured in the unit of GB or gigabyte. The smallest unit
depends on the size of the hard disk. The current system will divide the hard
disk space by 20 and take the nearest whole number as the smallest unit. For
example, when the disk total volume is less than 40 GB, the smallest unit is
1GB. Or when hard disk total volume is greater than or equal to 40GB and
less than 60GB, the smallest unit will be 2 GB, etc.
Please Note:
While creating non-RAID 1 or non-RAID 5 volume, when
system returns to Volume Setting page, you will see "Normal” in
the State column for the volume. But when creating RAID 1,
RAID 5 or RAID 5 with hot spare volume, the State column will
display Built (Building percentage: xx%). This is because
when creating RAID 1 or RAID 5 volume, though the volume is
created and client is able to perform save or retrieve function,
but because the system is still performing necessary processes in
the background (e.g. building RAID 1 consistency or RAID 5
parity) to ensure proper working of the system, thus please make
sure not to hot-swap the hard disk until the State column shows
the message: Normal.
Simple
A simple volume must be created in contiguous space of
the same hard disk, and the selected space will be created as
independent and with non-RAID mechanism hard disk. In
creating a simple volume, you can select only one hard disk at a
