Chapter4 Router Configuration
3-6
address of Server which distributes IP address to Client and record this IP
address and information of interface receiving the message so as to discover and
deal with Fake DHCP Server in time for administrator.
IP Address Repeated Detection Function
In order to prevent repeated IP address allocation resulting in address conflict,
before DHCP Server allocates IP address for DHCP Client, it needs to detect this
IP address.
Using Ping function to realize address detection. It judges whether there is
address conflict by testing whether DHCP Server can get the Ping response
within the specified time. The designation address sent by DHCP Server is the
ICMP message with address to be allocated. If it does not receive response
within specified time, it will continue to send ICMP message until the Ping
operation time reaches the maximum. If it still does not get response, it will
allocate address to Client so as to assure that the IP address allocated to Client is
unique.
Address Matching Detection Function (Anti-static IP User Function)
When DHCP Server allocates IP address to user, it will record the binding
relationship of IP address and MAC address. User can also configure user
address table manually (that is static binding of IP address and MAC address). In
order to prevent illegal user from configuring a static IP address and access other
network, if the corresponding relationship of IP address and MAC address
configured by user does not exist in the user address table of DHCP Server
(include the DHCP table dynamically recorded and user address table manually
configured), DHCP Server will not allow user to access network outside. This
function only takes effect when DHCP Client and DHCP Server are in the same
network segment.
3.2.3 DHCP Relay
DHCP Relay Application Environment
The original DHCP protocol requires that Client and Server must be in the same
network segment and cannot work across network segments. In order to configure
host dynamically, it needs to configure a DHCP Server in all network segments and
