Chapter7 Security Configuration
6-4
Objective
Step
Globally enable
IGMP Snooping
1. Use command of configure to enter the Global Configuration View;
2. Use command of igmp-snooping start to globally enable IGMP
Snooping;
3. Done.
Create multicast
VLAN
1. Use command of configure to enter the Global Configuration View;
2. Use command of vlan vlan-list to create VLAN which should be
enabled IGMP Snooping;
3. Use command of igmp-snooping mvlan vlan-id to create
corresponding multicast VLAN and enter the multicast VLAN configuration
view;
4. Done.
(Optional)
Configure
multicast data
forwarding mode
of multicast VLAN
1. Use command of configure to enter the Global Configuration View;
2. Use command of igmp-snooping mvlan vlan-id to enter the multicast
VLAN configuration view;
3. Use command of igmp-snooping forwarding-mode { ip | mac } to
configure multicast data forwarding mode;
4. Done.
Configure
interface to join in
VLAN and enable
IGMP Snooping
on interface
1. Use command of configure to enter the Global Configuration View;
2. Use command of interface fastethernet interface-number to enter the
Interface Configuration View;
3. Use command of port hybrid vlan vlan-list { tagged | untagged } to
configure interface to join in VLAN;
4. Use command of igmp-snooping enable to enable IGMP Snooping
function on interface;
5. Done.
Configure
interface to join in
static multicast
group
1. Use command of configure to enter the Global Configuration View;
2. Use command of interface fastethernet interface-number to enter the
Interface Configuration View;
3. Use command of igmp-snooping static-group group-address
group-address mvlan vlan-id to configure interface to join in static multicast
group;
4. Done.
Appendix List:
Parameter
Description
Value
vlan-id
VLAN ID
integer with range of 1-4094
interface-number
Ethernet port number
integer with range of
<1-8>/<0-4>/<1-48>
group-address
multicast IP address
224.0.0.0 -239.255.255.255
