Chapter7 Security Configuration
7-16
Parameter
Description
Value
or any both
7.2.6 Configure ACL Optional Function
Background Information
ACL optional function includes:
Create ACL effective time period
After creating ACL effective time period, when configuring ACL rule to refer to this
time period, the ACL rule is effective during the period; If configure the rule not
refer to this time period, the ACL rule is not subjected to the time limits unless
deleting the ACL.
Create ACL rate limitation template
After creating ACL rate limitation template, when configuring ACL rule to bind with
rate limitation template, the ACL rule can be used to filter data according to
different rate limitation rule.
Create ACL counting template
After creating ACL counting template, when configuring ACL rule to bind with
counting template, the ACL rule can be used to count data for statistic according
to different counting type.
Purpose
According to the real condition, configuring ACL optional function can provide variety
methods to filter data packet for user.
Process
According to different destination, please execute corresponding steps. Refer to the
following table.
Objective
Procedure
Creante ACL
effective time
period
1. Use command of configure to enter Global Configuration View;
2. Use command of time-range list LIST-NUMBER to enter Time-range
Configuration View;
3. Use the following commands to configure the absolute start and end time
of time-range module;
