![Qtech QSW-2870 [41/230] Tftp download file](/views2/1596592/page41/bg29.png)
Chapter1 Basic Configuration
1-34
Parameter
Description
Value
ipv4-address
Host IPv4 address
Dotted decimal
remotefile
File name to be uploaded from the
host to server
String form with length 1~63
filename
Local file name to be uploaded
String form with length 1~63
[ port-id ]
Port number, optional configuration
Integer form with range between
1~65535
config
Device config file to be uploaded
-
1.4.2.4 TFTP Download File
It is suggested to operate the command under the guide of engineers and technicians.
Purpose
When file download is required, the client side sends request packet to the TFTP
server and receives data from the server along with configuration towards it. In
practical device operation and maintenance, it is usually required that the config file or
OS is the host to the device for config modification or OS upgrade.
The command is applied for file downloading to the device..
Process
According to the different purposes, execute corresponding step. Please refer to the
following table.
Purpose
Process
Download remote file
via TFTP and save it to
local (applied for IPv4)
1. Use command of configure to enter the Global Configuration
View;
2. Use command of tftp get ipv4-address remotefile [ port-id ] or tftp
get ipv4-address remotefile localfile filename [ port-id ] to download
remote file via TFTP and save it to local;
3. Done.
Download remote file
via TFTP and save it to
local (applied for IPv6)
1. Use command of configure to enter the Global Configuration
View;
2. Use command of tftp6 get ipv6-address remotefile [ port-id ] or
tftp6 get ipv6-address remotefile localfile filename [ port-id ] to
download remote file via TFTP and save it to local;
Notice:
