Chapter1 Basic Configuration
1-25
Username and password configuration through command „adduser‟:
2. Start FTP client program at PC and establish FTP connection with the switch.
Upload switch application „switch.z‟ to switch Flash root and download configuration
file „config‟ from the switch. The FTP Client application shall be purchased and
installed by the user.
#fetch switch config file
If there is no sufficient switch Flash Memory, please delete the existing applications inside the Flash
and upload again.
The PC as the FTP server transmits mirror file with bin format, and config file with ASCII format.
3. Upgrade operation to the switch after the upload is finished.
QSW-2870 (config)#adduser switch password hello
ftp>ascii
200 Type is ASCII
ftp>get startcfg
150 Opening ASCII mode data connection
226 Transfer complete
ftp: receive 14251 bytes within 0.22Seconds 65.07Kbytes/sec.
C:\ftp 1.1.1.1
220 FTP Server ready User
(1.1.1.1none)): admin
331 Password required
Password:
230 User logged in
ftp>bin
200 Type set to I, binary mode
ftp> put switch.z
200 Port set okay
150 Opening BINARY mode data connection
226 Transfer complete
ftp: sends 3069212 bytes within 1.42Seconds 2158.38Kbytes/sec.
