Chapter1 Basic Configuration
1-6
the network connection is ok.
5. Input username and password (QSW-2870 Switch initialized
username is
„admin’ and password is „12345’) to access into the command line
interface for configuration, Successful:
1.3.3 Login through SSH
Purpose
This section introduces how to log into QSW-2870 Switch via SSH of local PC. The
SSH login is available when user has higher security requirement.
Network Environment
The requirement of network environment to SSH login can be referenced to
requirement of Console or telnet login.
Precondition
Before SSH login to QSW-2870 Switch, There is issue the user needs to confirm:
The command „sshd‟ for enabling SSH facility has already been
proceeded after a first power-up and device login via serial port.
