Chapter7 Security Configuration
6-6
Objective
Step
interface to join in
VLAN and enable
IGMP Snooping
protocol on
interface
2. Use command of interface fastethernet interface-number to enter the
Interface Configuration View;
3. Use command of port hybrid vlan vlan-list { tagged | untagged } to
configure interface to join in VLAN;
4. Use command of igmp-snooping enable to enable IGMP Snooping
function on interface;
5. Done.
Appendix List:
Parameter
Description
Value
vlan-id
VLAN item
integer with range of 1-4094
vlan-list
VLAN list
integer with range of 1~4094, form as 1,3-5
6.2.4 Configure IGMP Snooping
Background
IGMP Snooping based on VLAN runs on the Switch between router and user host. By
listening the IGMP Snooping message sent between upper router and host to
maintain the IGMP message forwarding table, so it can manage and control to
transmit the multicast data message to realize the multicast of Layer-2.
Procedure
According to the different purposes, execute corresponding step. Please refer to the
following table.
Objective
Step
Globally enable
IGMP Snooping
1. Use command of configure to enter the Global Configuration View;
2. Use command of igmp-snooping start to globally enable IGMP
Snooping;
3. Done.
Create multicast
VLAN
1. Use command of configure to enter the Global Configuration View;
2. Use command of vlan vlan-list to create VLAN which should be
enabled IGMP Snooping;
3. Use command of igmp-snooping mvlan vlan-id to create
corresponding multicast VLAN and enter the multicast VLAN configuration
view;
4. Done.
Configure
multicast data
1. Use command of configure to enter the Global Configuration View;
2. Use command of igmp-snooping mvlan vlan-id to enter the multicast
