Chapter7 Security Configuration
6-7
Objective
Step
forwarding mode
of multicast VLAN
VLAN configuration view;
3. Use command of igmp-snooping forwarding-mode { ip | mac } to
configure multicast data forwarding mode;
4. Done.
(Optional)
Configure IGMP
version
1. Use command of configure to enter the Global Configuration View;
2. Use command of igmp-snooping mvlan vlan-id to enter the multicast
VLAN configuration view;
3. Use command of igmp-snooping version { v1 | v2 | v3 } to confiugre
IGMP version;
4. Done.
(Optional)
Configure static
router interface
1. Use command of configure to enter the Global Configuration View;
2. Use command of igmp-snooping mvlan vlan-id to enter the multicast
VLAN configuration view;
3. Use command of igmp-snooping uplink-port fastethernet
interface-number to configure static router interface
4. Done.
(Optional)
Configure query
parameter
1. Use command of configure to enter the Global Configuration View;
2. Use command of igmp-snooping query-interval query-interval to
configure the interval of sending query message (all multicast VLAN share
to use this parameter);
3. Use command of igmp-snooping robust-count robust-count to
configure IGMP robust coefficient of query (all multicast VLAN share to use
this parameter);
4. Use command of igmp-snooping lastmember-queryinterval query-
lnterval to configure query interval of specific group query (all multicast
VLAN share to use this parameter);
5. Use command of igmp-snooping lastmember-querynumber
query-number to configure specific query time (all multicast VLAN share to
use this parameter);
6. Use command of igmp-snooping mvlan vlan-id to enter the
multicast VLAN configuration view;
7. Use command of igmp-snooping querier { enable | disable } to
configure IGMP Snooping query enabled state;
8. Use command of igmp-snooping max-response-time response-
time to configure the maximum response time fileld value of general query
message;
9. Done.
(Optional)
Configure
multicast policy
1. Use command of configure to enter the Global Configuration View;
2. Use command of igmp-snooping mvlan vlan-id to enter the
multicast VLAN configuration view;
