Chapter8 Reliability Configuration
8-19
Objective
Procedure
Configure Switch root
protection function
1. Use command of configure to enter Global Configuration
View;
2. Use command of stp to enter STP Configuration View
3. Use command of stp root-protection { enable | disable }
to configure Switch root protection function;
4. End.
Configure root protection
function of designated MSTI
1. Use command of configure to enter Global Configuration
View;
2. Use command of stp to access STP configuration view;
3. Use command of stp instance instance-id root-protection
{ enable | disable } to configure root protection function of
designated MSTI;
4. End.
Configure Switch TC
protection function
1. Use command of configure to enter Global Configuration
View;
2. Use command of stp to enter STP Configuration View
3. Use command of stp tc-protection { enable | disable } to
configure Switch TC protection function;
4. Use command of stp tc-hold-off { time | default } to
configure topology to change delay/restrain time;
5. End.
Attached List:
Parameter
Description
Value
time
delay/restrain time
To be from 4 to 30, unit: second
default
default value
10s
instance-id
STP instance ID
To be from 1 to 63
8.2.7 Maintenance and Debug
Purpose
When MSTP function is abnormal, user can use this operation to check or debug.
Process
According to different destination, please execute corresponding steps. Refer to the
following table.
Objective
Procedure
Enable STP
1. Keep current Privileged User View;
