![Qtech QSW-2870 [138/230] Maintenance and debug](/views2/1596592/page138/bg8a.png)
Chapter7 Security Configuration
6-11
Objective
Step
5. Done.
6.2.6 Maintenance and Debug
Purpose
When IGMP Snooping is abnormal and it needs to check, debug or locate problem,
user can use operation of this section.
Procedure
According to the different purposes, execute corresponding step. Please refer to the
following table.
Objective
Step
Enable IGMP
Snooping debug
function
1. Use command of disable to exit to the Common User View or Keep
current Privilege User View;
2. Use command of debug igmpsnoop to enable IGMP Snooping debug
function;
3. Done.
Disable IGMP
Snooping debug
function
1. Use command of disable to exit to the Common User View or Keep
current Privilege User View;
2. Use command of no debug igmpsnoop to disable IGMP Snooping
debug function;
3. Done.
Check IGMP
Snooping
configuration file
information
1. Use command of disable to exit to the Common User View or use
command of configure to enter the Global Configuration View or use
command of interface fastethernet interface-number to enter the Interface
Configuration View;
2. Use command of show igmp-snooping config to check IGMP
Snooping configuration file information;
4. Done.
Check IGMP
Snooping
interface
configuration file
information
1. Use command of disable to exit to the Common User View or use
command of configure to enter the Global Configuration View or use
command of interface fastethernet interface-number to enter the Interface
Configuration View;
2. Use command of show igmp-snooping interface to display IGMP
Snooping interface configuration file information ;
3. Done.
Check IGMP
Snooping
1. Use command of disable to exit to the Common User View or use
command of configure to enter the Global Configuration View or use
