Qtech QSW-2870 [83/230] Configure or delete vlan translation item
![Qtech QSW-2870 [83/230] Configure or delete vlan translation item](/views2/1596592/page83/bg53.png)
Chapter2 Layer 2 Ethernet Configuration
2-38
Objective
Step
Parameter
Bind VLAN
translation item to
interface
1. Use command of configure to enter the Global
Configuration View;
2. Use one of the following commands.
join translation-vlan map-index { in | out }
join translation-vlan map-indexlist { in | out }
Refer to the
following table.
Unbind VLAN
translation item of
interface
1. Use command of configure to enter the Global
Configuration View;
2. Use one of the following commands.
no join translation-vlan map-index { in | out }
no join translation-vlan map-indexlist { in | out }
Appendix List:
Parameter
Description
Value
map-index
VLAN translation item index
integer with range of 1~768
map-indexlist
multiple VLAN translation item index
integer, form as 1,2,5-10, to
be 1~768
in
take effect of ingress direction
-
out
take effect of egress direction
-
2.7.2 Configure or Delete VLAN Translation Item
Purpose
This section introduces how to configure or delete VLAN translation item.
Procedure
According to the different purposes, execute corresponding step. Please refer to the
following table.
Objective
Step
Parameter
Delete
inner or
outer VLAN
Tag
1. Use command of to enter the Common User View or the
Privilege User View;
2. Use one of the following commands.
translation-vlan map-index inner-vlan { vlan-id |
vlan-id1/vlan-id2 } delete { inner | outer } [nto1]
translation-vlan map-index inner-vlan { vlan-id |
vlan-id1/vlan-id2 } delete { inner | outer } nto1
translation-vlan map-index inner-vlan { vlan-id |
vlan-id1/vlan-id2 } delete inner delete outer
translation-vlan map-index inner-vlan { vlan-id |
Refer to the
following table.
