Chapter8 Reliability Configuration
8-28
When RLINK group is RLINK activated state, RLINK group mode cannot be modified.
Purpose
Using the operation in this section to configure Resilient Link group and its basic
function to realize redundancy link backup and fast switching under double uplinks
network environment.
Process
According to different destination, please execute corresponding steps. Refer to the
following table.
Objective
Procedure
Create RLINK
group and enter its
configuration view
1. Use command of configure to enter Global Configuration View;
2. Use command of rlink group rlink-group-number to create RLINK
group and enter its configuration view; If RLINK group has existed already,
use this command to enter its configuration view directly;
3. End.
Configure
RLINK group
mode to be single
or double mode
1. Use command of configure to enter Global Configuration View;
2. Use command of rlink group rlink-group-number to enter RLINK
Configuration View;
3. Use command of type { single | double } to configure RLINK group
mode;
4. End.
Configure
master and slave
interface of
RLINK group
1. Use command of configure to enter Global Configuration View;
2. Use command of interface fastethernet interface-number to enter
Interface Configuration View;
3. Use command of join rlink rlink-group-number { master | slave |
sender } to add interface to RLINK group and designate this interface to be
master or slave or sender;
4. End.
(Optional)
Configure sending
VLAN ID of
RLINK protocol
packet
1. Use command of configure to enter Global Configuration View;
2. Use command of interface fastethernet interface-number to enter
Interface Configuration View;
3. Use command of rlink group rlink-group-number send-vlan vlan-id to
configure sending VLAN ID of RLINK protocol packet ;
4. End.
Configure
protection VLAN
of RLINK instance
1. Use command of configure to enter Global Configuration View;
2. Use command of rlink group rlink-group-number to enter RLINK
Configuration View;
3. Use command of protect-vlan vlan-list to configure protection VLAN of
RLINK instance;
