Chapter2 Layer 2 Ethernet Configuration
2-32
Appendix List:
Parameter
Description
Value
description
specify VLANIF interface description information
character string, not
support blank, case
sensitive, length range of
character string is 1~32
vlan-id
specify the associated protocol VLAN ID
integer with range of
1~4094
protocol-id
the protocol identification of current interface outer
Tag
hex, <0x1-0xffff>
standard
standard value
0x8100
schedule-profile
the created enhanced load sharing template mode
-
Name
detailed template name
-
src-mac
specify trunk load sharing based on source MAC
address
-
dst-mac
specify trunk load sharing based on destination
MAC address
-
srcdst-mac
specify trunk load sharing based on XOR address
of source MAC and destination MAC
-
default
default mode
default load sharing
mode to be srcdst-mac
mac-vlan
first match VLAN according to the VLAN divided
based on MAC
-
ip-subnet-vlan
first match VLAN according to the VLAN divided
based on IP sub-network
-
2.6.8 Maintenance and Debug
Purpose
When VLAN function is abnormal, it needs to check and debug.
Procedure
According to the different purposes, execute corresponding step. Please refer to the
following table.
Objective
Step
Enable or
disable VLAN or
VLANIF traffic
statistics switch
1. Use command of configure to enter the Global Configuration View;
2. Use command of interface vlan vlan-id to enter the VLANIF
Configuration View or use command of vlan vlan-id1 [vlan-id2] to create
one or more VLAN and enter the VLAN Configuration View;
