Chapter2 Layer 2 Ethernet Configuration
2-8
Objective
Step
Parameter
integer with range of
1~16000
2.2.2.8 Configure Ethernet Interface Priority
Background
By configuring the priority of different interfaces, it assures that the most important
service cannot be influenced by delay or discard and guarantees the network efficient
running at the same time.
Procedure
According to the different purposes, execute corresponding step. Please refer to the
following table.
Objective
Step
Parameter
Configure
Ethernet interface
priority
1. Use command of configure to enter the
Global Configuration View;
2. Use command of interface interface-type
interface-number to enter one specified
interface configuration view;
3. Use command of priority [level]
interface default
priority to be 0
2.2.2.9 Configure Ethernet Interface MTU
Background
When exchanging data in high throughput such as file transmission, it may encounter
the long frame more than the standard Ethernet frame length. Use the following
command to configure the frame size.
The MTU of Ethernet interface only influences the IP packaging on Ethernet interface
or packet disassembly. The MTU of using Ethernet _II form is 1500. The MTU of using
Ethernet _SNAP form is 1492.
Procedure
According to the different purposes, execute corresponding step. Please refer to the
following table.
Objective
Step
Parameter
Configure the
MTU of Ethernet
1. Use command of configure to enter the
Global Configuration View;
MTU, integer with
range of 64-9000, unit:
