Chapter2 Layer 2 Ethernet Configuration
2-9
Procedure
According to the different purposes, execute corresponding step. Please refer to the
following table.
Objective
Step
Clear the statistics
information of current
Ethernet interface
1. Use command of configure to enter the Global Configuration
View;
2. Use command of interface interface-type interface-number to
enter one specified interface configuration view;
3. Use command of reset counter.
2.2.2.12 Descript Ethernet Interface
Purpose
Use the following command to configure interface description character string to
distinguish each port.
Procedure
According to the different purposes, execute corresponding step. Please refer to the
following table.
Objective
Step
Parameter
Configure
Ethernet interface
description
character string
1. Use command of configure to enter the
Global Configuration View;
2. Use command of interface interface-type
interface-number to enter one specified
interface configuration view;
3. Use command of description description
no description
information default
description: interface
description
information, character
string, not support
blank, case sensitive
Delete Ethernet
interface
description
character string
1. Use command of configure to enter the
Global Configuration View;
2. Use command of interface interface-type
interface-number to enter one specified
interface configuration view;
3. Use command of no description
description
2.2.3 Ethernet Interface Senior Attribution Configuration
2.2.3.1 Configure Interface Loopback Detection
Purpose
