Chapter2 Layer 2 Ethernet Configuration
2-21
Objective
Step
specified LACP
group
information
command of configure to enter the Global Configuration View or use
command of interface fastethernet interface-number or interface eth-trunk
trunk-number to enter the Interface Configuration View or keep the current
Privilege User View;
2. Use command of show lacp trunk [ trunk-id ] to display all or specified
LACP group information;
3. Done.
Check related
configuration
information of
LACP
1. Use command of disable to exit to the Common User View or use
command of configure to enter the Global Configuration View or use
command of interface fastethernet interface-number or interface eth-trunk
trunk-number to enter the Interface Configuration View or keep the current
Privilege User View;
2. Use command of show lacp system to display related configuration
information of LACP ;
3. Done.
Appendix List:
Parameter
Description
Value
rx
received data packet
-
tx
data packet sent
-
timer
timer
-
event
event notification
-
churn
churn state machine
-
mux
Muxstate machine
-
logic
choice logic
-
sync
synchronization
-
all
all information
-
2.5.4 Example
Network Requirement
Configure link aggregation group on two directly connected Switches to increase the
bandwidth and reliability between the two devices. And the detailed requirements are
as the following.
The link between two devices has the ability of redundant backup. When part of
the links is failed, the backup link can be used to replace the fault link and keep
the transmission no-break.
