Chapter1 Basic Configuration
1-33
Purpose
Process
function
Configuration View;
2. Use command of no ttftpd6 to close device TFTP6 server
function;
3. Done.
1.4.2.3 TFTP Upload File
It is suggested to operate the command under the guide of engineers and technicians.
Purpose
When the switch needs to upload file to TFTP server, the switch as client side sends
request packet towards TFTP server and sends data to the server along with
confirmation from it. The following commands can be applied for file upload.
Process
According to the different purposes, execute corresponding step. Please refer to the
following table.
Purpose
Step
Upload local
file to remote
TFTP server
(applied for
IPv4).
1. Use command of configure to enter the Global Configuration View;
2. Use command of tftp put ipv4-address remotefile config or tftp put ipv4-
address remotefile localfile filename [ port-id ] to upload local file to remote
TFTP server;
3. Done.
Upload local
file to remote
TFTP server
(applied for
IPv6).
1. Use command of configure to enter the Global Configuration View;
2. Use command of tftp6 put ipv6-address remotefile config or tftp6 put
ipv6-address remotefile localfile filename [ port-id ] to upload local file to remote
TFTP server;
3. Done.
Parameter Description
Parameter
Description
Value
Ipv6-address
Host IPv6 address
Pure binary indication: 128 0s
and1s with 16 bits for each group
and 8 groups in total
Notice:
