Chapter8 Reliability Configuration
8-21
Objective
Procedure
interface
2. Use command of show stp instance instance-id interface to display STP
instance configuration information of all interface ;
Or Use command of show stp instance instance-id interface fastethernet
interface-number to display STP instance configuration information of
designated interface ;
3. End.
Check
configuration
information of
all interface
STP
1. Use command of disable to exit to Normal User View, or use command of
configure to enter Global Configuration View, or use command of interface
fastethernet interface-number or interface eth-trunk trunk-number to enter
Interface Configuration View, or use command of stp to enter STP
Configuration View or no use any command to keep current Privileged User
View;
2. Use command of show stp interface to display configuration information
of all interface STP;
3. End.
Check
configuration
information of
designated
interface STP
1. Use command of disable to exit to Normal User View, or use command of
configure to enter Global Configuration View, or use command of interface
fastethernet interface-number or interface eth-trunk trunk-number to enter
Interface Configuration View, or use command of stp to enter STP
Configuration View or no use any command to keep current Privileged User
View;
2. Use command of show stp interface fastethernet interface-number
Or Use command of show stp interface eth-trunk trunk-number to display
configuration information of designated interface STP;
3. End.
Attached List:
Parameter
Description
Value
interface-number
Ethernet interface number
to be from <1-12>/<1-18>
trunk-number
Trunk interface number
to be from 1 to 128
instance-id
MSTI ID
to be from 1 to 63
8.2.8 Example
Network Requirements
Now there are four Switches to support MSTP protocol. They are SwitchA, SwitchB,
SwitchC and SwitchD. SwitchA and SwitchB are the QSW-2870 series Switch.
SwitchC and SwitchD are other series Switch produced by Qtech. Configure MSTP
basic function as following:
