Chapter4 Router Configuration
3-16
Parameter
Description
Value
vlan-id
VLAN ID
integer with range of 1~4094
ip-address
the DHCP server IP address of DHCP relay
agent
dotted decimal
drop
If message has the Option82, then drop
this message.
-
keep
If message has the Option82, then keep
the Option82 content unchanged and
transmit it.
-
replace
If message has the Option82, then replace
the original Option82 of the message
-
circuitid
sub-option of DHCP relay, circuit ID
character string
remoteid
user defined remote ID sub-option content
Remote ID includes device MAC address
default. If using command to configure this
sub-option content, then the Remote ID of
option82 is the content configure.
character string, case
sensitive
ip-address
DHCP Client IP address
dotted decimal
mac-address
DHCP Client MAC address
form as
AA:BB:CC:DD:EE:FF, A~F is
one hex number
interval
the timing updating period of DHCP relay
user table
integer with range of
60~3600, unit: second
default
default value of the timing updating period
of DHCP relay user table
1800s
3.2.8 Maintenance and Debug
Purpose
When DHCP function is abnormal, it can use this section operation to check and
debug.
Procedure
According to the different purposes, execute corresponding step. Please refer to the
following table.
Objective
Step
Enable DHCP
Relay debug
function
1. Keep the current Privilege User View;
2. Use command of debug dhcp relay to enable DHCP Relay debug
function;
