Chapter8 Reliability Configuration
8-13
8.2.5 Configure MSTP Parameter
Background Information
Before modifying MSTP parameters, please first finish the following tasks.
Configure interface physical attribute
Configure interface to join in VLAN
Configure Switch to join in designated MST domain
Purpose
Introduce how to modify MSTP parameters in this section.
In some specific network environment, user can modify MSTP parameters to achieve
the best result.
Process
According to different destination, please execute corresponding steps. Refer to the
following table.
Objective
Procedure
Configure STP
forward delay
1. Use command of configure to enter Global Configuration View;
2. Use command of stp to enter STP Configuration View
3. Use command of stp forward-delay { forward-delay | default } to
configure STP forward delay;
4. End.
Configure interval
to send hello
message for
protocol
1. Use command of configure to enter Global Configuration View;
2. Use command of stp to enter STP Configuration View
3. Use command of stp hello-time { hello-interval | default } to
configure interval to send hello message for protocol;
4. End.
Configure the
maximum aging
time of Switch STP
1. Use command of configure to enter Global Configuration View;
2. Use command of stp to enter STP Configuration View
3. Use command of stp max-age { max-age | default } to configure the
maximum aging time of Switch STP;
4. End.
Configure the
maximum hops of
STP MST domain
1. Use command of configure to enter Global Configuration View;
2. Use command of stp to enter STP Configuration View
3. Use command of stp max-hop { max-hop | default } to configure the
maximum hops of STP MST domain;
4. End.
