Chapter7 Security Configuration
7-18
Objective
Procedure
filter rule-number outaction { red | yellow } drop
filter rule-number outaction { red | yellow } remark-dscp dscp
filter rule-number outaction { red | yellow } remark-dot1p priority
filter rule-number car car-value outaction drop
6. End.
Create ACL
counting
template
1. Use command of configure to enter Global Configuration View;
2. Use command of counter counter-number (packet/byte|all) sort
(green/red/greenred/greenyellow/redyellow|total) to configure counter
template;
3. Use command of filter-list acl-number to enter ACL Configuration View;
4. Use command of filter rule-number action counter counter-number to
bind counting template with ACL;
5. End.
Attached List:
Parameter
Description
Value
LIST-NUMBER
time-range module list name
to be from 1 to 128
RANGE-NUMBER
Range number
to be from 1 to 16
hh:mm:ss
Start or end
time(hour:minute:second)
to be
<0-23>:<0-59>:<0-59>
YY/MM/DD
Start or end time(year/month/day)
to be
<2000-2100>:<1-12>:<1-31>
mm:ss
Start or end time(minute:second)
to be <0-59>:<0-59>
MM
Month
to be from 1 to 31
(mon|tue|wed|thu|fri|sat
|sun)
Week
-
MM/DD
Start or end time(month/day)
to be <1-12>:<1-31>
acl-number
Access Control List
to be from 1 to 4000
<1-1000>: layer2 ACL
<1001-2000>: IPv4ACL
<2001-3000>: Mixed ACL
<3001-4000>:IPv6ACL
meter number
Meter number
to be from 1 to 256
CIR number
CIR item number
to be from 8 to
4294967295
CBS number
CBS item number
to be from 10000 to
4294967295
EBS number
EBS item number
to be from 10000 to
4294967295
