Chapter2 Layer 2 Ethernet Configuration
2-28
Objective
Step
Hybrid type interface to join in the VLAN based on IP sub-network;
Done.
Configure VLAN
based on IP
sub-network and at
the same time
configure
corresponding VLAN
802.1p priority of IP
sub-network
1. Use command of configure to enter the Global Configuration View;
2. Use command of ip-subnet-vlan ip-address mask-address vlan-id
priority priority or use command of ip-subnet-vlan ip-address/mask-length
vlan-id priority priority or use command of ip-subnet-vlan ip-address mask-
address vlan-id or use command of ip-subnet-vlan ip-address/mask-length
vlan-id to configure VLAN based on IP sub-network and at the same time
configure corresponding VLAN 802.1p priority of IP sub-network;
3. Done.
Appendix List:
Parameter
Description
Value
ip-address
specify the pursuant source IP address or
network address of VLAN divided based on IP
sub-network
dotted decimal
mask-address
specify sub-network mask
dotted decimal
vlan-id
specify to divide VLAN ID based on IP sub-
network
integer with range of
1~4094
priority
optional, specify corresponding VLAN 802.1p
priority of IP address or network segment
integer with range of 0~7,
the value is bigger, the priority
is higher, default to be 0
2.6.6 Configure VLAN Based on Protocol
Purpose
This section introduces how to configure VLAN divided based on protocol.
Procedure
According to the different purposes, execute corresponding step. Please refer to the
following table.
Objective
Step
Configure to divide
VLAN based on
protocol and specify
the associated
protocol
1. Use command of configure to enter the Global Configuration View;
2. Use command of protocol-vlan protocol-index { ethernet2 | snap }
etransm-typevalue } or use command of protocol-vlan protocol-index llc
ssap { ssap-value | any } dsap { dsap-value | any } to configure to divide
VLAN based on protocol and specify the associated protocol;
