Chapter2 Layer 2 Ethernet Configuration
2-15
According to the different purposes, execute corresponding step. Please refer to the
following table.
Objective
Procedure
Parameter
Add static
ARP
mapping
table
1. Use command of configure to enter the
Global Configuration View;
2. Use command of interface vlan N1 to enter
the vlan N1 Configuration View;
3. Use command of ip arp ip-address
mac-address fastethernet interface-number;
system ARP table default
to be empty, obtain address
mapping by dynamic ARP
ip-address: static ARP
mapping IP address, dotted
decimal
mac-address: static ARP
mapping MAC address, to be
one hex
interface-number: Ethernet
interface number, integer,
<1-8>/<0-4>/<1-48>
Delete
static ARP
mapping
item
1. Use command of configure to enter the
Global Configuration View;
2. Use command of interface vlan N1 to enter
the vlan N1 Configuration View;
3. Use command of no ip arp ip-address;
2.4.2 Clear Dynamic ARP Table
Purpose
This section introduces how to clear dynamic ARP mapping table.
This section helps user to delete device all dynamic ARP mapping table items
manually when necessary.
Execute this command to cancel the mapping relationship of IP address and MAC
address and may result in that user cannot access some nodes, so user needs to use
this command carefully.
Procedure
According to the different purposes, execute corresponding step. Please refer to the
following table.
Objective
Step
Clear dynamic ARP
mapping table
1. Use command of configure to enter the Global Configuration View;
2. Use command of flush arp dynamic.
2.4.3 Check ARP Information
Purpose
