![Qtech QSW-2870 [166/230] Configure layer3 acl6](/views2/1596592/page166/bga6.png)
Chapter7 Security Configuration
7-12
Attached List:
Parameter
Description
Value
acl-number
Access Control List
to be from 1 to 4000
<1-1000>: layer2 ACL
<1001-2000>: IPv4ACL
<2001-3000>: mixed ACL
<3001-4000>: IPv6ACL
rule-number
Rule number of ACL
to be from 1 to 16384
src-mac-address/M| any
Source MAC address
information of ACL rule
M is integer with range of from 1 to
24
any means any source MAC
address
dst-mac-address/M |any
Destination MAC
address information of ACL
rule
M is integer with range of from 1 to
24
any means any destination MAC
address
src-mac-mask
Source MAC address
mask information of ACL
rule
dotted decimal
dst-mac-mask
Destination MAC
address mask information
of ACL rule
dotted decimal
provider
(<1-4094>/<1-4094>)
(any|<0-7>) customer
(any|<1-4094>)(any|<0-7>)
VID/VID range or both of
them
-
rule-number
Rule number of ACL
to be from 1 to 16384
VLAN ID
VLAN ID
to be from 1 to 4094
7.2.5 Configure Layer3 ACL6
Background Information
One ACL is composed of some rules and actions.
Before configuring Layer3 ACL6 rules, first need to create one Layer3 ACL6 and
specify ACL type number to be from 3001 to 4000.
Process
According to different destination, please execute corresponding steps. Refer to the
following table.
