Chapter1 Basic Configuration
1-21
Process
According to the different purposes, execute corresponding step. Please refer to the
following table.
Purpose
Step
(IPv4)Uploa
d local file to
remote FTP
server
1. Use command of configure to enter the Global Configuration View;
2. Use command of ftp put ipv4-address user password remotefile config or
use command of ftp put ipv4-address user password remotefile localfile
filename [ port-id ] to upload local file to remote FTP server;
3. Done.
(IPv6)Uploa
d local file to
remote FTP
server
1. Use command of configure to enter the Global Configuration View;
2. Use command of ftp put ipv6-address user password remotefile config or
use command of ftp put ipv6-address user password remotefile localfile
filename [ port-id ] to upload local file to remote FTP server;
3. Done.
Appended List:
Parameter
Description
Value
ipv4-address
Host IPv4 address
Dotted decimal
ipv6-address
Host IPv6 address
In the IPv6 address form, 128 bits IP
address is distributed as 8 groups that 12
bits in each group is indicated with 4
hexadecimal characters (0~9, A~F) and
separated with punctuation „:‟, where
each „X‟ is indicating a group of
hexadecimal value
user
Username for FTP service login
String form with length 1~63
password
Password for FTP service login
String form with length 1~63
remotefile
File name that is to be
downloaded to the host
String form with length 1~63
filename
Designated local file name
String form with length 1~63
[ port-id ]
Port number, optional
configuration
Integer form with value range between
1~65535
config
Device config file to be uploaded
-
1.4.1.4 FTP Download File
Purpose
This section introduces how to download file through FTP.
Process
