Qtech QSW-2870 [71/230] Configure vlan based on mac address
![Qtech QSW-2870 [71/230] Configure vlan based on mac address](/views2/1596592/page71/bg47.png)
Chapter2 Layer 2 Ethernet Configuration
2-26
Objective
Step
default VLAN of trunk interface;
4. Done.
Appendix List:
Parameter
Description
Value
vlan-id
VLAN ID
integer with range of 1~4094
vlan-list
specify the VLAN list of trunk interface
form as 1,3,5~8, integer with range of
1~4094
default
the VLAN ID of trunk interface recover
to be the default value
default:1, default to be VLAN1
2.6.4 Configure VLAN Based on MAC Address
Purpose
This section introduces how to configure divided VLAN based on MAC address.
Procedure
According to the different purposes, execute corresponding step. Please refer to the
following table.
Objective
Step
Enable or disable
divided VLAN based on
MAC address of interface
1. Use command of configure to enter the Global Configuration View;
2. Use command of interface fastethernet interface-number or
interface eth-trunk trunk-number to enter the Interface Configuration
View;
3. Use command of mac-vlan { enable | disable } to enable or disable
divided VLAN based on MAC address of interface;
4. Done.
Configure interface to
allow VLAN based on
MAC address to pass
1. Use command of configure to enter the Global Configuration View;
2. Use command of interface fastethernet interface-number or
interface eth-trunk trunk-number to enter the Interface Configuration
View;
3. Use command of port link-type hybrid to configure interface link
type to be hybrid;
4. Use command of port hybrid vlan vlan-list untagged } to configure
Hybrid interface to join in the VLAN based on MAC address;
Done.
Configure to
associated MAC address
1. Use command of configure to enter the Global Configuration View;
2. Use command of mac-vlan mac-address/mac-mask vlan-id priority
