Chapter2 Layer 2 Ethernet Configuration
2-5
Objective
Step
Parameter
designate the port is working under half-
duplex mode
2.2.2.4 Configure Ethernet Interface Rate
Background
The following command can be used to set the Ethernet port rate. When the port to be
rate provisioned is working under auto-negotiation mode, its rate is auto-negotiated
and determined by both the local port and peer port.
Procedure
According to the different purposes, execute corresponding step. Please refer to the
following table.
Objective
Step
Parameter
Configure
Ethernet port
rate
1. Use command of configure to enter the
Global Configuration View;
2. Use command of interface interface-type
interface-number to enter one specified interface
configuration view;
3. Use command of speed 10/100/1000 to set
different rates for the interface as respectively
10Mbit/s, 100Mbit/s and 1000Mbit/s.
In default, when the port
is working under
non-auto-negotiation
mode, its rate is the
maximum rate supported
by the port type.
2.2.2.5 Configure Ethernet Interface Flow Control
Background
When local and peer switches both start function of flow control, the local switch
sends message to peer switch to inform peer switch to stop sending message if
congestion happens to local switch; on the other side the peer switch will stop
message sending to local switch once it receives the inform message, and vice versa.
The mechanism is able to avoid message loss. The following command can be used
to enable or disable local Ethernet port flow control. Once disabled, the port will no
longer send flow control frame to peer.
Procedure
According to the different purposes, execute corresponding step. Please refer to the
following table.
