Chapter8 Reliability Configuration
8-18
deletion operation will cause great burden to the device and bring great hidden
trouble to the network stability.
After enabling TC-BPDU message attack function, the number of times which
MSTP processes BPDU message of TC type can be configured per unit time. If
the number of BPDU messages of TC type received by MSTP process exceeds
the configured threshold, the MSTP process only deals with the designated times
specified by threshold. For other BPDU messages of TC type beyond the
threshold, after the timer expires, MSTP process only deals with once. In this way,
it can avoid frequent deletion of MAC table item and ARP table item so as to
protect the Switch.
Purpose
When need to configure MSTP protection, user can use this section operation.
Process
According to different destination, please execute corresponding steps. Refer to the
following table.
Objective
Procedure
Configure BPDU protection
function
1. Use command of configure to enter Global Configuration
View;
2. Use command of stp to enter STP Configuration View
3. Use command of stp bpdu-guard { enable | disable } to
configure BPDU protection function;
4. End.
Open BPDU protection
blocked port
1. Use command of configure to enter Global Configuration
View;
2.Use command of interface fastethernet interface-number
or interface eth-trunk trunk-number to enter Interface
Configuration View;
3. Use command of stp bpdu-guard-forward to open BPDU
protection blocked port;
4. End.
Configure Switch loop
protection function
1. Use command of configure to enter Global Configuration
View;
2. Use command of stp to enter STP Configuration View
3. Use command of stp loop-protection { enable | disable }
to configure Switch loop protection function;
4. End.
