Chapter1 Basic Configuration
1-31
Process
#enter global configuration view and input command to conduct FTP connection by
inputting correct username and password for FTP server login.
#Download upgrading program to the „download‟ category of switch and process the
upgrading through upgrading command. The new mirror file will take effect only after
the switch is rebooted.
1.4.2 TFTP Configuration
1.4.2.1 TFTP Introduction
Trivial File Transfer Protocol (TFTP) was initially introduced for no-disk system
conducting (usually work station or X terminal). Comparing with another file
transmission protocol FTP, the TFTP does not have complex interactive access
interface or authority control that it is suitable for environment with no complex
interaction between client and server. The TFTP protocol is usually implemented
based on UDP.
The protocol transmission of TFTP is conducted by the client side. When file
downloading is required, a request packet will be sent from client side to TFTP server
and data will be received from the server along with confirmation towards it; when file
uploading is required on the other side, request packet will be sent from the client side
to the TFTP server and data will be received to the server along with confirmation from
it. The transmission mode of TFTP is binary mode.
QSW-2870 (config)#ftp get 10.18.1.2 123 123 d:\upgrade.z
Local path is “Ram:/flash/download”.
getting data…
3069212 bytes downloaded
QSW-2870 (config)#upgrade os
WARNING:System will upgrade! Continue?[y/n]
System now is upgrading, please wait.
%Local path is “Ram:/flash/download”.
QSW-2870 (config)#reboot
