![Qtech QSW-2870 [197/230] Attached list](/views2/1596592/page197/bgc5.png)
Chapter8 Reliability Configuration
8-15
Objective
Procedure
management path
cost of instance 0
interface eth-trunk trunk-number to enter Interface Configuration View;
3. Use command ofstp { enable | disable } to enable or disable
interface STP function;
4. Use command ofstp path-cost { cost | default } to configure
interface management path cost of instance 0;
5. End.
Configure count
standard of STP
interface path cost
1. Use command of configure to enter Global Configuration View;
2. Use command of stp to enter STP Configuration View
3. Use command of stp pathcost-standard { dot1t | dot1d-1998 } to
configure count standard of STP interface path cost;
4. End.
Configure current
interface to execute
mode check
operation
1. Use command of configure to enter Global Configuration View;
2. Use command of interface fastethernet interface-number or
interface eth-trunk trunk-number to enter Interface Configuration View;
3. Use command of stp { enable | disable } to enable or disable
interface STP function;
4. Use command ofstp mcheck to configure current interface to
execute mode check operation
5. End.
Configure STP
migration time cycle
1. Use command of configure to enter Global Configuration View;
2. Use command of stp to enter STP Configuration View
3. Use command of stp migration-time { migration-time | default } to
configure STP migration time cycle;
4. End.
Configure whether
to enable point-to
-point link detection
1. Use command of configure to enter Global Configuration View;
2. Use command of stp to enter STP Configuration View
3. Use command of stp link-detection { enable | disable } to enable or
disable point-to point link detection;
4. End.
Configure whether
to enable STP Trap
function
1. Use command of configure to enter Global Configuration View;
2. Use command of stp to enter STP Configuration View
3. Use command of stp trap { enable | disable } to enable or disable
STP Trap function;
4. End.
Attached List:
Parameter
Description
Value
forward-delay
STP forward delay
to be from 4 to 30, unit: second
default
Default value
15s
