Chapter1 Basic Configuration
1-22
According to the different purposes, execute corresponding step. Please refer to the
following table.
Purpose
Step
(IPv4)Downloa
d remote file and
save to local
1. Use command of configure to enter the Global Configuration View;
2. Use command of ftp get ipv4-address user password remotefile
[ port-id ] or use command of ftp get ipv4-address user password remotefile
localfile filename [ port-id ] or use command of ftp get ipv4-address user
password remotefile config to download remote file and save to local;
3. Done.
(IPv6)Downloa
d remote file and
save to local
1. Use command of configure to enter the Global Configuration View;
2. Use command of ftp6 get ipv6-address user password remotefile
[ port-id ] or use command of ftp6 get ipv6-address user password remotefile
localfile filename [ port-id ] or use command of ftp6 get ipv6-address user
password remotefile config to download remote file and save to local;
3. Done.
Appended List:
Parameter
Description
Value
ipv4-address
Host IPv4 address
Dotted decimal
ipv6-address
Host IPv6 address
In the IPv6 address form, 128 bits IP
address is distributed as 8 groups that 12
bits in each group is indicated with 4
hexadecimal characters (0~9, A~F) and
separated with punctuation „:‟, where each
„X‟ is indicating a group of hexadecimal
value
user
Username for FTP service
login
String form with length 1~63
password
Password for FTP service
login
String form with length 1~63
remotefile
File name that is to be
downloaded to the host
String form with length 1~63
filename
Designated local file name
String form with length 1~63
[ port-id ]
Port number, optional
configuration
Integer form with value range between
1~65535
config
Device config file to be
uploaded
-
